BLA Swage Fork Terminals – Stainless Steel
$8.39 – $10.64
Description
316 grade stainless steel swage forks. Commonly used in industrial and balustrade applications
Additional information
| Weight | 0.03 kg |
|---|---|
| Dimensions | 2.1 × 7.4 × 1.3 cm |
| Variation: | 162275 – 5/32 '' WIRE 8MM PIN, 162278 – 5/32 '' WIRE 6MM PIN, 162293 – 3MM WIRE 5MM PIN, 162294 – 3MM WIRE 6MM PIN |
| BLA Code | Wire Dia. mm | Wire Dia. in | A mm | B mm | C mm | D mm | Breaking Load |
|---|---|---|---|---|---|---|---|
| 162293 | 3 | – | 69 | 5 | 9 | 9.5 | 700 |
| 162294 | 3 | – | 69 | 6 | 9 | 9 | 1250 |
| 162278 | 4 | 5/32 | 72 | 6 | 9 | 9.5 | 1250 |
| 162275 | 4 | 5/32 | 77 | 8 | 11 | 11 | 1800 |
