Mastervolt Sine Wave Inverter - Mass Sine 230V

Mastervolt Sine Wave Inverter – Mass Sine 230V

$1,229.00 – $5,799.00
SKU: G110444

Description

For the toughest tasks. Even under the most extreme conditions the products from the Mass series operate faultlessly, giving you round-the-clock output when necessary. With an MTBF of 180,000 hours at full capacity and 24/7 use, the Mass products are ideal for the toughest tasks and any situation that requires a reliable power supply.

Features
• For heavy duty work in professional and semi- professional applications
• Full capacity at temperatures up to 104°F
• Pure sine wave output prevents failures and damage to connected sensitive equipment
• High peak capacity for the seamless switching on of complex and heavy loads
• Dynamic, battery-specific input current for an optimal use of every type of battery (Mass Sine Ultra Inverter)
• Parallel configuration of up to ten devices for a capacity up to 40 kW (Mass Sine Ultra Inverter)
• 3-Phase configuration for a capacity up to 36 kW (Mass Sine Ultra Inverter)
• Integrated MasterBus (Mass Sine Ultra Inverter) or MasterBus compatible (Mass Sine Inverter)
• Suitable for mobile applications
• Professional connections
• Automatic, reliable and safe operation
• Optional Masterswitch/Systemswitch for automatic selection of the desired energy source Supplies your system without battery

Additional information

Weight 11.06 kg
Dimensions 55.8 × 40.6 × 20.3 cm
Variation:

110444 – Dec-00, 110448 – 24/800, 110450 – 24/1500, 110452 – 24/2500, 110453 – ULTRA 24/4000, 110454 – 24/5000

User Reviews

0.0 out of 5
★★★★★
0
★★★★★
0
★★★★★
0
★★★★★
0
★★★★★
0

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

BLA Code 110444 110448 110450 110452 110454 110453
Description Mass Sine 12/2000 Mass Sine 24/800 Mass Sine 24/1500 Mass Sine 24/2500* Mass Sine 24/5000* Mass Sine Ultra 24/4000
General Specifications
Nominal battery voltage 12V 24V 24V 24V 24V 24V
Minimum battery capacity >200Ah >50Ah >150Ah >200Ah >400Ah >350Ah
Output voltage (± 5%) 230V – 50Hz (± 0 .01Hz) 230V – 50Hz (± 0 .01Hz) 230V – 50Hz (± 0 .01Hz) 230V – 50Hz (± 0 .01Hz) 230V – 50Hz (± 0 .01Hz) 230V – 50Hz (± 0 .01Hz)
P30 power at 40°C, cos phi 1 2000 W 800 W 1500 W 2500 W 5000 W –
Continuous power at 40°C, cos phi 1 1800 W 650 W 1200 W 2000 W 4000 W 4000 W
Peak load 4000 W 1600 W 2900 W 5000 W 9000 W 7000 W
Output waveform true sine true sine true sine true sine true sine true sine
Efficiency 0.92 0.92 0.92 0.92 0.92 0.92
Display/read-out LED display LED display LED display LED display LED display LED display
Dimensions, H x W x D mm 420 x 318 x 136 325 x 220 x 111 340 x 261 x 130 420 x 318 x 130 470 x 315 x 254 472 x 318 x 178
Weight kg 14.6 3.9 8 14.6 25 15
Approvals CE, E-mark, ABYC A-31 CE, E-mark, ABYC A-31 CE, E-mark, ABYC A-31 CE, E-mark, ABYC A-31 CE, E-mark, ABYC A-31 CE, E-mark, ABYC A-31
Technical Specification
Technology HF switch mode HF switch mode HF switch mode HF switch mode HF switch mode HF switch mode
Low battery voltage, switches off at 10V, ± 0.5V 19V, ± 0.5V 19V, ± 0.5V 19V, ± 0.5V 19V, ± 0.5V 19V, ± 0.5V
Low battery voltage, switches on at 11V, ± 0.5V 22V, ± 0.5V 22V, ± 0.5V 22V, ± 0.5V 22V, ± 0.5V 24V, ± 0.5V
High battery voltage, switches off at 15.5V, ± 0.5V 32V, ± 0.5V 32V, ± 0.5V 33V, ± 0.5V 32V, ± 0.5V 32V, ± 0.5V
High battery voltage, switches on at 14.5V, ± 0.5V 30V, ± 0.5V 30V, ± 0.5V 31V, ± 0.5V 30V, ± 0.5V 29V, ± 0.5V
Max. ripple on DC (battery) 5% RMS 5% RMS 5% RMS 5% RMS 5% RMS 5% RMS
Input current (nominal load) 183A 36A 68A 115A 230A 200A
No load power consumption: • ‘on’ mode (230V) • stand-by (scan mode) 480 mA – 6 W 50 mA – 0.6 W 240 mA – 5.6 W 35 mA – 0.8 W 200 mA – 5 W 25 mA – 0.6 W 250 mA – 6 W 25 mA – 0.6 W 250 mA – 6 W n.a. 300 mA – 7 W 25 mA – 0.6 W
Minimal DC fuse (slow blow)** 250A 63A 100A 160A 1x 250A or 2x 125A 250A
Minimal cable size 70 mm² 16 mm² 25 mm² 50 mm² 2x 70 mm² 70 mm²
Harmonic distortion typical <5% <5% <5% <5% <5% <1%
Cos Phi all power factors allowed all power factors allowed all power factors allowed all power factors allowed all power factors allowed all power factors allowed
Temperature range (ambient temp.) -25°C–80°C, >40°C derating -13°F–176°F, >104°F derating -25°C–80°C, >40°C derating -13°F–176°F, >104°F derating -25°C–80°C, >40°C derating -13°F–176°F, >104°F derating -25°C–60°C, >40°C derating -13°F–140°F,
Cooling natural/forced natural/forced natural/forced natural/forced natural/forced natural/forced
Protection degree IP23 IP23 IP23 IP23 IP23 IP23
Protections over temperature, over load, short circuit, high battery, low battery ✓ ✓ ✓ ✓ ✓
MasterBus compatible yes, using a MasterBus Inverter Interface or AC power analyser ✓ ✓ ✓ ✓ ✓
AC connection internal internal internal internal internal internal
Options
Model C4-RI 110522 Remote control on/off for the Mass Sine inverter. Remote control on/off for the Mass Sine inverter.
Masterlink/MICC 110688 Battery consumption meter for 2 batteries, 12/24V DC with LCD read-out, remote control for Mass Sine inverter and Mass battery charger or Mass Combi. Battery consumption meter for 2 batteries, 12/24V DC with LCD read-out, remote control for Mass Sine inverter and Mass battery charger or Mass Combi.
MasterBus Inverter Interface 110568 Integrates the Mass Sine inverter in a MasterBus network in a MasterBus network. Integrates the Mass Sine inverter in a MasterBus network in a MasterBus network.
Transfer system The Masterswitch and Systemswitch can be connected to all inverters. The Masterswitch and Systemswitch can be connected to all inverters.
