Blue Sea Systems 187 Series Circuit Breakers

Variation:

Clear

SKU: GBS-7036

Description

Provides circuit protection for 25 to 200 amp loads when switching and circuit protection are both required

Features
• Self-trimming case eliminates need for mounting panels or trim bezels
• Visible yellow reset lever shows open condition
• Trip-free design cannot be held closed after trip
• Recessed mounting holes for clean appearance

Specifications
• Interrupting Capacity 5,000A @ 12V DC, 3,000A @ 24V DC, 1,500A @ 42V DC
• Voltage Max. Operating 48V DC
• Temperature Min. Operating -40°C
• Temperature Max. Operating 85°C
• Type Thermal
• Class Type III – Switchable/Manual Reset – Trip Free
• Terminal Stud 5⁄16″-18
• Terminal Stud Torque 75 in-lb max.
• Trip Time Delay See bluesea.com
• Mounting Hole Accepts #10 (M5) Screw

Additional information

Variation:

BS-7036 – 187-SERIES 30A PANEL MOUNT, BS-7038 – 187-SERIES 40A PANEL MOUNT, BS-7039 – 187-SERIES 50A PANEL MOUNT, BS-7040 – 187-SERIES 60A PANEL MOUNT, BS-7041 – 187-SERIES 70A PANEL MOUNT, BS-7044 – 187-SERIES 100A PANEL MOUNT, BS-7048 – 187-SERIES 150A PANEL MOUNT, BS-7049 – 187-SERIES 200A PANEL MOUNT, BS-7140 – 187-SERIES 60A SURFACE MOUNT, BS-7144 – 187-SERIES 100A SURFACE MOUNT, BS-7148 – 187-SERIES 150A SURFACE MOUNT, BS-7149 – 187-SERIES 200A SURFACE MOUNT

Dimensions

Weight	0.2268 kg
Dimensions	5.51 × 12.07 × 19.69 cm

Panel Mount BLA Code

Surface Mount BLA code

Amps

BS-7036

BS-7038

BS-7039

BS-7040

BS-7140

BS-7041

BS-7044

BS-7144

100

BS-7048

BS-7148

150

BS-7049

BS-7149

200
