Mastervolt DC-DC Converter - Mac & Magic

Mastervolt DC-DC Converter – Mac & Magic

Price range: $419.90 through $529.00
SKU: G110510

Description

Mastervolt DC-DC Converter – Mac & Magic (SKU: G110510) offers reliable and efficient power conversion for your marine electrical systems. Designed to meet the demanding needs of boat owners, this converter ensures your onboard electronics receive stable and precise voltage, enhancing the safety and longevity of your equipment.

With advanced features such as high efficiency, adjustable output voltage, and robust protection mechanisms, the Mastervolt DC-DC Converter is perfect for maintaining optimal performance of sensitive devices and batteries, even in challenging marine environments. Its compact design and natural cooling make installation straightforward, while low sound levels ensure quiet operation onboard.

  • Nominal Input Voltage: 24V DC
  • Input Range: 20–32V DC
  • Factory Output Setting: 13.6V DC (adjustable 10–15V DC)
  • Maximum Output Power: 300W (270W nominal)
  • Maximum Current: 20A
  • Stabilised Output: 2% at extremes of temperature, load, and input
  • Ripple: Max. 1% peak-to-peak
  • Efficiency: >90% at nominal input voltage, up to 92% peak
  • Protection: Overload and over-temperature protection
  • 3-Step Charge Option: Yes (DIP switch settings)
  • Cooling: Natural cooling
  • Sound Level: <30 dBA at 1 meter
  • Dimensions (H x W x D): 190 x 130 x 61 mm
  • Weight: 1 kg
  • Approvals: CE certified
  • MasterBus Compatible: Yes, with MasterBus Serial Interface (optional)
  • Protection Degree: IP21

Upgrade your vessel’s power management with the Mastervolt DC-DC Converter and experience peace of mind, knowing your electronics are protected and powered efficiently, wherever your journey takes you.

Additional information

Variation:

110510 – NON ISOLOATED 24/12-20, 110512 – 12/12/2020, 110514 – 12/24-10, 110516 – 24/12/2020, 110518 – 24/24-20

Dimensions
Weight1.16 kg
Dimensions23.9 × 17.1 × 6.9 cm
BLA Code110510110516110518110512110514
DescriptionMac 24/12-20Magic 24/12-20Magic 24/24-20Magic 12/12-20Magic 12/24-10
Specifications Input
Nominal input voltage24V24V24V12V12V
Input range20–32V DC19–32V DC19–32V DC11–16V DC11–16V DC
Input range, 3-step charge mode24–32V DC24–32V DC24–32V DC12–16V DC12–16V DC
Lower input set point20V DC*20V DC*20V DC*10V DC*10V DC*
Delay lower input set point30 sec.*30 sec.*30 sec.*30 sec.*30 sec.*
Specifications Output
Factory setting13.6V DC*13.6V DC*27.2V DC*13.6V DC*27.2V DC*
Voltage adjustable*10–15V DC10–15V DC20–28.5V DC10–15V DC20–28.5V DC
Output voltage dimmer*4–13V DC4–13V DC8–26V DC4–13V DC8–26V DC
Stabilised2% at extremes of temperatures, load and input2% at extremes of temperatures, load and input2% at extremes of temperatures, load and input2% at extremes of temperatures, load and input2% at extremes of temperatures, load and input
Ripplemax. 1% peak peakmax. 1% peak peakmax. 1% peak peakmax. 1% peak peakmax. 1% peak peak
Power (max./nominal)300 / 270 W300 / 300 W580 / 580 W300 / 300 W300 / 300 W
Max. current20A20A20A20A10A
Charge current – 3-step mode16A16A16A16A8A
General Specifications
Galvanic isolationnoyesyesyesyes
Voltage limitedyesyesyesyesyes
Efficiency>90% (at nominal input voltage, full load); 92% peak>90% (at nominal input voltage, full load); 92% peak>90% (at nominal input voltage, full load); 92% peak>90% (at nominal input voltage, full load); 92% peak>90% (at nominal input voltage, full load); 92% peak
Protected against over loadyesyesyesyesyes
Protected against over temperatureyesyesyesyesyes
Dimmer functionyes, by external momentary switch via fast-on connection, to be activated by DIP-switch settingyes, by external momentary switch via fast-on connection, to be activated by DIP-switch settingyes, by external momentary switch via fast-on connection, to be activated by DIP-switch settingyes, by external momentary switch via fast-on connection, to be activated by DIP-switch settingyes, by external momentary switch via fast-on connection, to be activated by DIP-switch setting
Alarm contactnoyes (fast-on connector)yes (fast-on connector)yes (fast-on connector)yes (fast-on connector)
Dimensions, H x W x D mm190 x 130 x 61227 x 154 x 81227 x 154 x 81227 x 154 x 81227 x 154 x 81
Weight kg11.81.81.81.8
ApprovalsCECECECECE
Technical Specifications
3-Step charge optionyes (DIP switch settings)yes (DIP switch settings)yes (DIP switch settings)yes (DIP switch settings)yes (DIP switch settings)
DC consumption<30 mA<115 mA<115 mA<115 mA<115 mA
Connections input/outputscrew terminals, maximum wire size 16 mm2 / AWG5screw terminals, maximum wire size 16 mm2 / AWG5screw terminals, maximum wire size 16 mm2 / AWG5screw terminals, maximum wire size 16 mm2 / AWG5screw terminals, maximum wire size 16 mm2 / AWG5
Temperature range (ambient temp.)-25°C–80°C, >40°C derating / -13°F–176°F, >104°F derating-25°C–80°C, >40°C derating / -13°F–176°F, >104°F derating-25°C–80°C, >40°C derating / -13°F–176°F, >104°F derating-25°C–80°C, >40°C derating / -13°F–176°F, >104°F derating-25°C–80°C, >40°C derating / -13°F–176°F, >104°F derating
Coolingnatural coolingmaintenance free vario fansmaintenance free vario fans
Sound level<30 dBA at 1 mtr<48 dBA at 1 mtr<48 dBA at 1 mtr<48 dBA at 1 mtr<48 dBA at 1 mtr
Protection degreeIP21IP21IP21IP21IP21
MasterBus compatibleyes, by means of MasterBus Serial Interface (110572)yes, by means of MasterBus Serial Interface (110572)yes, by means of MasterBus Serial Interface (110572)yes, by means of MasterBus Serial Interface (110572)yes, by means of MasterBus Serial Interface (110572)
Options
EasyView 5 110661Touch screen panel for reading status and dimmer function settings.Touch screen panel for reading status and dimmer function settings.Touch screen panel for reading status and dimmer function settings.Touch screen panel for reading status and dimmer function settings.Touch screen panel for reading status and dimmer function settings.
MasterBus Serial Interface 110572Integrates the Mac & Magic converters in a MasterBus network.Integrates the Mac & Magic converters in a MasterBus network.Integrates the Mac & Magic converters in a MasterBus network.Integrates the Mac & Magic converters in a MasterBus network.Integrates the Mac & Magic converters in a MasterBus network.
