Description

Single Function Control
A durable chrome finish control with stainless steel lever arms, suitable for exposed installations. Controls with throttle lever have a twist grip throttle brake to handle larger diesel mechanism throttle/governor loads. Suits inboards with hydraulic gearbox, stern drives and outboards.
Features

• One function, one or two levers

• One handle for gear, one handle for throttle

• Available as throttle only, or gear and throttle, or twin throttle

• The throttle brake is simply applied by twisting the lever once the desired setting has been established

• Detents for forward/neutral/reverse incorporated in gear controls

• Can be used for dual station installations, where both stations move together, although care must be taken to avoid operating one station if the other throttle is firmly dampened down

• Especially suitable for engines with heavy governor load (i.e. Gardner diesel)

Cables
Accepts universal 3300/33C series Cables, CC230, CC330, CC332, CCX632 and CCX633. Fittings for these Cables are supplied with control. Also accepts 40/43 series Cables. Fittings for these Cables are also supplied with control.
Materials

• Marine quality chrome plated

• Die-cast zinc alloy housing

• Stainless steel lever arms

• Die-cast zinc alloy internal

rocker arm

Accessories
306878 3300/33C series dual station kit (1 per pair of levers)
